Navimow i-Series

Optimize your Navimow i-Series robotic mower with our improved blade disc! Thanks to its 9-blade technology, it ensures a cleaner cut and longer blade life. Choose from three sizes for different mowing requirements.

Suitable for:

✔ Navimow i-Series models: i105E / i108E

🔹 Variants & specifications:

🟢 Standard blade disc (182 mm)

• Diameter: 182 mm | Cutting width: 213 mm | Weight: 107 g (without blades)

• No adapter required | Easy assembly

• 9 blades for better cutting quality

🔵 XL blade disc (210 mm)

• Diameter: 210 mm | Cutting width: 245 mm | Weight: 143 g (without blades)

• Important: Only compatible with XL blade guard

• 9 blades for longer service life

🔴 XXL blade disc (230 mm)

• Diameter: 230 mm | Cutting width: 265 mm | Weight: 165 g (without blades)

• Important: Blade guard must be removed for assembly

• Maximum efficiency & best cutting performance

Your advantages at a glance

✅ True-to-original cutting heights
✅ Perfect fit: Compatible with (Ø 7 mm bolt circle) Blades & M4 screws
✅ Ultra-lightweight & stable construction
✅ 9-blade holder for maximum cutting surface
✅ Longer service life thanks to free-spinning bearing
✅ 4-way blade usage (2-hole system)
✅ Smooth-coated surface – hardly any sticking
✅ Easy installation, just like the original
✅ FEM design optimized for power transmission for maximum load capacity
✅ Premium engineering plastic: UV, water, chemical, cold, and heat resistant, as well as impact and tensile strength
✅ Integrated brass threaded bushings (M4) for secure fastening
✅ Optional: Improved blade guard for less dirt adhesion
✅ Available in anthracite & orange

📦 Scope of delivery
1 × 9-blade tuning blade disc – without blades
Including stainless steel T-spacer sleeves

Please note that there may be slight differences between the product and the photos shown, particularly in terms of color, shade, and texture. However, these differences do not affect the function or quality of the product.

Important note: The blade disc must be installed in accordance with the manufacturer's instructions and at your own risk. All manufacturer's information remains valid, in particular the safety instructions and the limited warranty.

Perfection for Navimow i105E & i108E
Flawless lawns in no time: With the enlarged 9-blade EasyCut tuning blade disc from GreenGears3D, your Navimow i model becomes a true precision tool.

Your advantages at a glance

✅ Suitable for: Navimow i-Series i105E & i108E
✅ Dimensions: 210 mm Ø | 245 mm cutting width
✅ Ultra-lightweight & stable: Only 143 g – protects the motor & battery
✅ Original cutting heights: 100% identical to the factory blade disc
✅ Perfect fit: Compatible with (Ø 7 mm bolt circle) blades & M4 screws
4-way blades: Economical 2-hole design
✅ Free blade movement: Freely rotating blades for clean cuts
✅ Integrated brass threaded inserts: 9 × M4 – secure, durable fastening
✅ Smooth-coated surface: Hardly any grass or dirt adhesion
✅ 1:1 assembly: Just like the original – quick and easy
✅ Force flow-optimized design: FEM-analyzed for maximum load capacity
✅ Premium plastic: UV-resistant, water- and chemical-resistant, cold/heat-resistant, impact-resistant, and tensile-resistant

Colors: Anthracite

📦 Scope of delivery
Larger 9-blade EasyCut tuning blade disc for Navimow i105E & i108E (without blades)
Includes stainless steel T-spacer sleeves

Please note:
Slight variations in color, shade, or texture between the product and photos are possible, but do not affect function or quality.

Important note: Assembly and operation are at your own risk. All manufacturer's information, in particular safety instructions and warranty conditions, remain valid without restriction.

Perfection for Navimow i105E & i108E
A flawless lawn in no time: With the 9-blade EasyCut knife plate from GreenGears3D, your Navimow i model catches every blade precisely and ensures even mulching.

Your advantages at a glance

✅ Suitable for: Navimow i-Series i105E & i108E
✅ Dimensions: 230 mm Ø | 265 mm cutting width
✅ Ultra-light & stable: Only 165 g – protects the motor & battery
✅ Original cutting heights: 100% identical to the factory blade disc
✅ Perfect fit: Compatible with Ø 7 mm mounting-hole blades & M4 screws
✅ 4-way blades: Economical 2-hole design
✅ Free blade movement: Blades mounted on ball bearings for clean cuts
✅ Integrated brass threaded inserts: 9 × M4 – secure, durable fastening
✅ Smooth-coated surface: Hardly any grass or dirt adhesion
✅ 1:1 installation: Just like the original – quick and easy
✅ Force flow-optimized design: FEM-analyzed for maximum load capacity
✅ Premium plastic: UV-resistant, cold/heat-resistant, impact-resistant & tensile-resistant

Colors: Anthracite

📦 Scope of delivery
1 × Enlarged 9-blade EasyCut tuning blade disc for Navimow i105E & i108E (without blades)
Includes stainless steel T-spacer sleeves

Please note:
Slight variations in color, shade, or texture between the product and photos are possible, but do not affect function or quality.
Important note: Assembly and operation are at your own risk. All manufacturer's information, in particular safety instructions and warranty conditions, remain valid without restriction.

Blade disc adapter

Models: Navimow i-Series i105E / i108E

Compatibility:
This adapter is specially designed for use with our blade discs and ensures a precise reduction of the cutting height by 5 millimeters.

Installation instructions:

• Only use our blade discs and the screws provided or screws of exactly the same length (M4 x 16 mm long).
• Using the wrong screw length can affect the stability of the adapter and compromise safety.

Important information:

• Not compatible with other blade discs or adapters.
• Ensure that assembly is carried out in accordance with the instructions and that all screws are tightened securely.

This blade & screw set is suitable for our 9x blade discs.

• They can be used up to 4 times in a completely new condition thanks to their 2 holes.
• The knife set is made of carbon steel and is coated with titanium, which ensures a high level of robustness

This knife & screw set is suitable for all knife plates offered.

Technical data:

• Material: Titanium carbide-coated stainless steel
• Dimensions: 36.2 x 18 x 0.85 mm
• Hole diameter: 7 mm (double hole)
• Mounting screws: 7 M4 screws

The blade set contains 45 blades and 45 M4 mounting screws, ensuring excellent durability and a precise, clean cut.

We recommend securing the blades with the screws and safety paint provided.

Warnings:

Caution: Sharp blades. Risk of injury. Use only with compatible robotic lawn mowers. Keep away from children.

1x set of screws for mounting our tuning discs 1x set contains three cylinder head screws with hexagon socket:

• M4x12mm, dimensions as for the original screws
• Hexagon socket
• High-strength alloy steel, strength class 12.9
• Rolled washer and spring washer

Installation instructions: The installation is carried out in accordance with the robotic lawnmower manufacturer's instructions. Please observe the

Safety instructions: Always follow the safety instructions of the robotic lawnmower manufacturer.
Risk warning: Use these screws at your own risk due to individual intervention.

Warranty: Please note that replacing the blade disc with an accessory such as our tuning blade discs may limit or affect the robotic lawnmower's warranty.

Safety information:

Maximize safety and compatibility with our extra-large blade protection, perfectly matched to the Navimow I and our XL blade disc (210 mm).

Product details:

• Extra-large protection area: specially developed for use with our XL blade disc (210 mm) – more area, more safety
• Perfect fit: tailor-made for Navimow I – sits securely and stably
• High-quality technical plastic: weather and UV-resistant thanks to 3D printing from robust ASA material

• Safe & reliable: Effectively protects people, animals and the surrounding area from the rotating blades
• Easy to assemble: Quick to assemble, no special tools required
• Color: Discreet anthracite – a perfect visual match for the robot

Ideal for anyone who wants to equip their Navimow I with a larger blade disc but still wants to ensure safety.
